Auto Part Mold Manufacturer

Molds for optically clear lense, clear cut-off line, high-temperature resistant PC material. Mold steel Groditz 1.2343ESR/1.2344ESR, side gate.

Injection moulded fresnel lens with high light transmittance, high efficiency in focusing and high precision. Mold with two cavities, mold life 800,000 shots.

Transparent light guide with side gate. Considering the poor mobility of PC material, we make a moldflow simulation to check the pressure near the gates and adopt proper gates in mold design.

Knowing the importance of luminance, lit appearance, and optics to the optical part, we design the P/L and insert line away from the light source input face and output face.

Double color lens mold for car head lighting, UV coating, mold steel NAK80/1.2343ESU. Mold rotates 180°. Accurate parting surface and sealing surface are required for the smooth joint.

High glossy bezel mold, PC black+PC clear, texture on A surface, hot runner system with side gate. Cavities 2LH+2RH, mold size 1,620*1,170*860mm, two barrels injection machine 1,200T.
